AIS 84C2

Features

The Model AIS 84C2 Accelerometer is designed for high performance applications. The accelerometer incorporates a gas-damped piezoresistive MEMS sensing element providing outstanding long-term stability. Ranges from ±200 g to 2000 g with high frequency response, this sensor also meets the specification SAE J211. The model 84C2 provides a millivolt output signal and features mechanical overload stops that provide shock protection to loads greater than 10,000g. Signal amplified versions are optional.

Applications

  • Crash Testing
  • Vibration & Shock Monitoring
  • Impact Testing
  • Automotive Comfort Testing
  • Truck Testing

Service

  • Sinusoidal Calibration
  • Pendulum Calibration
  • Connector Options
  • Signal Conditioning
  • Repair Options
  • ID-Module Options
